China Factory Industrial Customized Technical CNC Machining High Precision MGO Magnesia Yttria Partial Stabilized Ysz Zro2 Zirconia Ceramic Parts

Overview

Basic Info.

Model NO.	Customized
Tolerance	Od and ID Best to Be 0.005mm
Usage	High Precision Structure Ceramic Parts
Certificate	RoHS, Reach, ISO9001:2008
Transport Package	Individual Packaging
Specification	Max. OD to be 800mm
Trademark	JingHui
Origin	China
HS Code	8547100000
Production Capacity	5000000PCS/Month

Product Description

China Factory Industrial Customized Technical CNC Machining High Precision MgO Magnesia Yttria Partial Stabilized Ysz Zro2 Zirconia Ceramic PartsProduct Description

The main characteristics of zirconia ceramic parts

1. Excellent wear resistance, much higher 276 times than stainless steel2. Higher density than most technical ceramics, over than 6 g/cm33. High hardness, over 1300 MPa for Vicker4. Can withstand higher temperatures up to 2400°5. Low thermal conductivity, less than 3 W/m.k at room temperature6. Similar coefficient of thermal expansion as stainless steel7. Exceptional fracture toughness reaches up to 8 Mpa m1/28. Chemical inertness, aging resistance, and not rust forever 9. Resistance to molten metals due to an extraordinary melting point

The specification of ceramic parts

Material option	Zirconia (ZrO2), Alumina(Al2O3), Silicon carbide(SiO2), Silicon nitride(Si3N4)
Forming methods	Dry pressed, Ceramic injection molding, Hot pressed, ISO pressed
Available types	Flanged tubes, slotted tubes, one-end closed tubes, square tubes
Specification	OD can be from 1 to 50mm, length can be from 10mm to 500mm
Precision processing	CNC machining, Precision grinding, Polishing, Lapping,
Tolerance	The tolerance of OD and ID can be 0.001mm, the tolerance of length can be 0.001mm
Surface quality	Free of cracks, foreign contamination, mirror surface better than Ra0.1
Key parameters	Roughness to be Ra0.05, Parallelism to be 0.001mm

The description of zirconia ceramic parts
Zirconium oxide, also called Zirconia, is an extremely tough technical ceramic with a hardness of >9 Mohs.Zirconia has the highest strength and fracture toughness at room temperature among all the advanced ceramic materials,In addition to withstanding attacks from molten metal, organic solvents, strong acids, and strong alkalis.So zirconia ceramic parts are always used in various severe service conditions.Jinghui ceramics provide many selections of zirconia ceramic parts in different types of partial stabilizers,such as yttria (Y2O3) stabilizer, magnesia stabilizer, and cerium stabilizer, also support various customized ceramic parts, including ceramic tubes, ceramic rings, ceramic shafts, ceramic rod. With our in-house comprehensive manufacturing equipment, we are capable of achieving ultra-precision ceramic components. Whatever, it's a prototyping case or high volume demand, we believe we could help your business grow.

Products category

Datasheet of Technical ceramics

Our Advantages

Manufacturing flow chart of technical ceramic parts

We have in-housing comprehensive manufacturing types of equipment, including forming, sintering, CNC machining, precision grinding, laser cutting, and so on, which help us to control the quality very well. Also, it greatly benefits cost control.

Certifications

Our Partners

FAQ

Q1. Are you a factory or trading company?
A: We are a manufacturer with over 12 years of experience. You are welcome to visit our factory.Q2: Do you send a sample to check?
A: Sure, the sample is free and freight collect.Q3: When will you ship it?
A: If the products are in storage, we'll ship within 48 hoursQ4: When can I get the price?
A: We regularly quote within 24 hours after we get your inquiry. If you are in urgent need of getting the price.Please call us or tell us in your email so that we will proceed with your inquiry as a priority.Q5: Is it available to provide customized products?
A: We always support custom-made demand as per different materials, dimensions, and designs.
