Planetary Ball Mill Small Ball Mill Price for Calcium Carbonate Gypsum Limestone Quartz Graphite Calcite Feldspar Fluorite Powder Factory

Planetary Ball Mill Small Ball Mill Price for Calcium Carbonate Gypsum Limestone Quartz Graphite Calcite Feldspar Fluorite Powder Factory

Product Overview Ball mills/ball mill machine/ball mill grinding description: Ball mills are the key equipment for grind;
Basic Info.
Model NO. Clriik
Condition New
Warranty 1 Year
After-sales Service Technical Support
Ball Mill Grinding Capacity 20-200 T/H
Ball Mill Grinding Certification CE
Ball Mill Grinding Fineness 30-400 Mesh
Ball Mill Grinding Weight 4.6-260t
Ball Mill Grinding Mining Object Cement Ball Mill
Ball Mill Grinding Max Feeding Size 25 Mm
Ball Mill Grinding Power 18-800
Ball Mill Grinding Grinding Index 5.5-13
Ball Mill Grinding Color You Need
Ball Mill Grinding Warranty 12 Months
Transport Package Export Standard
Specification CE
Trademark Clirik
Origin China
HS Code 84742090
Production Capacity 10-128 Tph
Product Description
Product Overview
Ball mills/ball mill machine/ball mill grinding description:
Ball mills are the key equipment for grinding after the crushing process, which is widely used in the manufacture industries, such as cement, silicate, new building material, refractory material, fertilizer, ferrous metal, nonferrous metal and glass ceramics and can be used for the dry and wet grinding for all kinds of ores and other grind-able materials. This ball mill machine changes the intrinsic grinding mill structure. Its body and ground plank are an integral whole. So when fixing, it can be lowered on a plane surface once only. Use double tiered roller axletree with centripetal spherical surface as the support of the host axletree can reduce energy cost by 30%. The intrinsic grille pattern forcing evacuation is instead by over fall pattern controlling one. This can improve the milling of the granule and the quantity dealt with is reduced by 15-20%.Ball Mill Technical Parameters
ModelCylinder rotary speed
(r/min)
Loading ball weight
(t)
Input size
(mm)
Discharge size
(mm)
Capacity
(t/h)
power
(kw)
Weight
(t)
900×1800391.5≤200.075-0.890.8-218.54.6
900×3000392.7≤200.075-0.891-4225.6
1200×3000363.5≤250.074-0.41.6-53712.8
1200×4500325≤250.074-0.41.6-5.85513.8
1500×3000277.5≤250.074-0.42-57515.6
1500×57002812≤250.074-0.43.5-613024.7
1830×30002511≤250.074-0.44-1013028
1830×64002421≤250.074-0.47-1621034
1830×70002423≤250.074-0.48-1824536
2100×36002319≤250.074-0.410-3621046
2200×45002127≤250.074-0.412-2328048.5
2200×65002135≤250.074-0.414-2638052.8
2200×70002135≤250.074-0.415-2838054
2200×75002135≤250.074-0.415-3038056
2400×45002130≤250.074-0.418-4532065
2400×80002036≤250.074-0.420-4841081
2700×36002139≤250.074-0.419-7540083
2700×40002040≤250.074-0.420-7840085
2700×45002048≤250.074-0.422-8543089
3200×45001865≤250.074-0.429-140800137
3200×54001881.6≤250.074-0.430-180800-1000146
3600×45001788≤250.074-0.435-2101000190
3600×600017117≤250.074-0.438-2401250-1500220
3600×850017144≤250.074-0.445-2601800260

Ball mill working principle:The ball mill is a horizontal rotating device transmitted by the outer gear. The materials are transferred to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of steel balls in the chamber. The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials. The ground materials are discharged through the discharging board thus the grinding process is finished.Ball mill/ball mill machine/ball mill grinding features&advantages:1. high production capacity and crushing ratio;2. low power consumption, uniform particle size;3. simple structure, easy to operate;4. low investment cost, big profit;5. perfect services, both before-sales servies and after-sales services.

Ball mill/ball mill machine/ball mill grinding Packing & Shipping

Packing: Conventional Packaging suitable for long distance transportation.

Shipping: 10-30 working days after recieving the deposit of the devices.


Company Profile
Company information:Shanghai Clirik Machinery Co., Ltd. is located in Pudong New District, Shanghai, China, which is specialing in manufacturing grinding mills, Raymond mills, crushers and other associate accessories with decades experience. We have strong and professional technical and sale team. Customers' satisfaction is our final and forever pursuing.
Our ServicesPre-sale service:


1.Clirik provides a variety of mining equipment for you to choose from.
2.Clirik will recommend suitable production lines and grinding equipment to you according to your site.3.Clirik customizes the logo and color of the grinding equipment according to your company image.4.Clirik provides third party inspection to ensure the quality of your grinding equipment.After-sales service:
1. Clirik provides you with online installation and use videos.2. Clirik will provide you with technicians to install and debug the grinding equipment.3. Clirik trains you the technicians who use and maintain the grinding equipment.4. Clirik provides you with a one-year warranty and lifetime service for the grinding equipment.
Our Certificate
Our workshop


Our Customer visiting


Other Products Offered

Micro Powder Grinding MillUltrafine Vertical Roller MillHigh Pressure Suspension Grinding Mill
Finished Size:300-2500(mesh) Capacity:0.5-45(t/h)
Pass rate: D97 5 micron
Finished Size: 600-4500(mesh)
Capacity: 3-20(t/h)Pass rate: D50 2 micron
Finished Size: 50-450(mesh)Capacity: 1-28(t/h)Pass rate: D90 30 micron
FAQ

1. What advantages does your ball mill have?

The main advantage of our ball mill over other kinds of mills is that you can grind a friable or crystalline material to fine average particle size and classify in a very narrow particle size range at the same time.

2. What particle size range does your ball mill produce?

Typically the Clirik ball mill will grind friable or crystalline materials down to the 0.075 -0.4/0.89 mm average particle size range. Particles larger than 10 microns are generally hard-to-fracture polymers such as toner compounds or hard waxes, and some organic materials, but if a larger size is wanted, many products can be ground larger than 10 microns by reducing power to the mill or by increasing the rate of feed. Some products are simply polished to remove sharp edges by running at elevated feed rates with low grinding pressure, a process that changes how the material compacts.
*If you would like more details,please contact our customer service
